jacking TESLA MODEL S 2017 Owner's Manual (UK)

1. CloseTouch the circled X in the top left corner of a window to close it (or you can touch anywhere
outside the window).
2. Sunroof
If Model S is equipped with a sunroof, touch to adjust its position (see Sunroof on page 15).
3. Suspension
If Model S is equipped with Smart Air Suspension, touch to manually raise or lower Model S, orto remove a previously saved auto-raising location (see Smart Air Suspension on page 110).
Model S must be powered on and you must press the brake pedal before you can change
suspension settings. Smart Air Suspension causes Model S to self-level, even when powered
off. Therefore, when towing or lifting, you must disable self-leveling (see Instructions for
Transporters on page 173 and Jacking and Lifting on page 157).
4. Driving

Jacking Procedure
Follow the steps below to lift Model S. Ensure
that any non-Tesla repair facility is aware of
these lifting points.
1. Position Model S centrally between the lift posts.
2. If your Model S is equipped with Smart Air Suspension, it automatically self-levels,
even when power is
off. Use the
touchscreen to set the suspension as
follows:

Wheel SpecificationsWheel TypeLocationSizeOffset
19"
Front8.0J x 191.575"
40 mmRear8.0J x 191.575"
40 mm21" - Silver (standard)Front8.5J x 211.575"
40 mm21" - Grey (standard)Rear8.5J x 211.575"
40 mm21" - Silver and Grey (optional) Performance
Plus vehiclesRear9.0J x 211.575"
40 mmRoad Wheel Nut Torque129 lb. ft (175 Nm)Note: For instructions on how to jack/lift Model S, see Jacking and Lifting on page 157.
Tire Specifications
Tire TypeLocationSize19" wheelsAllP245/45R1921" wheelsFront
RearP245/35R21
P265/35R21**On a P85D and P90D Model S, the width of the rear tires may vary depending on date of
manufacture. Some vehicles may be equipped with P245/35R21 tires on both front and rear.Tire pressures vary depending on the type of tires fitted. Refer to the tire pressures printed on
the Tire and Loading Information label. This label is located on the center door pillar and is
visible when the driver

heating 105height adjustments (suspension)auto-raising 110
automatic and manual settings 111
disabling (Jack mode) 111
high beam headlights 54
high voltageBattery specifications 166
components 131
safety 138
hills, stopping on 62
hitches 161
Home location 122
HomeLinkFCC certification 180
programming and using 126
hood 12
horn 39, 41
I
IC
certifications 179identification labels 159
Insane setting (dual-motor) 98
instant range 65
instrument panelcharging status 137
cleaning 150
overview of 45interiorcleaning 150
dimensions 162
lights 51
overview 2
temperature control 105
Internet radio 114
intrusion detection 125
ISOFIX child seats, installing 26
J
J1772 132
Jack mode 111
jacking 157
K
keyFCC and IC certifications 179
how to use 4
key not inside 43
ordering extras 5
replacing battery 5
keyless entry 4
LlabelStatutory Plate 160
Tire and Loading Information 160
lane assist 86
lane change flash 55
lane change, automatic 79
lane departure warning 86
Language & Units 101
language setting 101
Launch Mode 63
liftgateadjust opening height 10
opening 10
lifting 157
lightsadaptive headlights 54
hazard warning 55
headlights after exit 54
turn signals 54
load limits 160
location-based suspension 110
locking and unlocking doors 4
Ludicrous setting (dual-motor) 98
lumbar support 17
M
maintenancebrake fluid, checking 155
cleaning 149
daily and monthly checks 138
fluid replacement intervals 138
panel, removing 154
replacing wiper blades 152
service intervals 138
tires 139
washer
fluid, topping up 156
washer jets, cleaning 152
map updates 123
maps 119
mats 151
Max Battery Power 98
media 112
mileage upon delivery 177
mirrors 42
mobile app 130
Mobile Connectordescription 132
using 134
modifications 158
N
naming 104
navigation 119
Index
Index183
